512KB Memory Expansion Module for SHARP PC-1600 by Tom

After my PC-1500 memory module which need some corrections, i’m very proud to present you this incredible 512KB memory module for the PC-1600 built by Tom.
The best thing to do is to let Tom explain it :

At the beginning of 2014 I rediscovered the fascination of the vintage SHARP pocket computers. My very first computer was indeed a PC-1500/CE-150 which I found somewhere deep down in my storage. And it was still working (except the rechargeable battery of course)!

In the 80s, when I was a boy, however the PC-1600/CE-1600P was a dream, but too expensive for me by magnitudes. So I was lucky to buy one from ebay. Since I’m a computer scientist, I was interested to treat that machine like an embedded system using a modern software dev environment and the sdcc/Z80 C-compiler. I succeeded, but soon noticed that the RAM-disk was too small, even on a 32KB+64KB config.

So I searched for custom vintage Tramsoft and Bajic 256KB modules, but couldn’t get one.
That was the point, when I decided to build my own. Luckily I found the homepage of Kai Bader, who kindly offered me one of his breakout boards and I started experimenting with SRAM ICs.
The hard part for me was to decode the PC-1600 vertical bank switch of slot 2, but finally I got my first 256KB RAM module in my hands.

Version1
Technical Data (rev 1 – sold out)
———————————
* 256KB RAM module with low power SRAM chip
* 32KB can optionally be reserved as a main memory extension, the rest is used as RAM-disk
* No battery buffer

I send one to Kai and he posted it on his website. Allmost immediately I was contacted by Eric – the owner of this great site – who had some clever suggestions for technical improvements and organized a poll at the silicium.org enthusiasts forum for a revision 2 of the board.
Since my first version had a 512KB SRAM chip on board of which “only” 256KB was used, the main improvement was to provide a 2x256KB mode and a 512KB mode.
It was clear soon that the 512KB harware mode was not supported by the PC-1600 INIT-command, but after some fiddling about I managed to write a patch routine that overcomes this problem.
And that was the birth of the first 512KB RAM module for the SHARP PC-1600.

Version2
Technical Data (rev 2 – sold out)
———————————
* as rev 1 but 3 modes of operation:
– 256KB mode, without need of any additional init software or peeks/pokes
– 2x256KB mode, with two banks 256KB each – to be switched by an additional hardware switch
– 512KB mode, needs an additional custom patch routine to get that mode running
* Battery buffer not included, but a description for mod available.

For more details see
http://www.silicium.org/forum/viewtopic.php?f=24&t=38729&start=84

Technical Data (rev 3 – planned)
——————————–
* as rev 2 but with (better) battery buffer support incorporated

Thanx again Eric for your support and this very informative and entertaining site.

Thank you Tom for this module !
My friends from Silicium and me are happy with our 512KB PC-1600 🙂

>Click to download the full module description <<



My iPad3 as a CE-154 ?

I had to buy a cover for my iPad but didn’t find any matching my needs.
But on “Lakokine.com” there was the perfect item : strong with personalization with my own design.

Here is the result :

iPad3_1
iPad3_2
iPad3_3

It’s perfect to store my manuals and documentations 🙂

User manuals for the Hiradastechnika PTA-4000, PTA-4000+16 and KA160

Nowhere else you can find these rare manuals !
Please don’t share them elsewhere, put only the link to this page.

These manuals are for :
– PTA-4000 pocket computer
– PTA-4000+16 pocket computer
– KA-160 printer

Manuals HULink
HU_PTA-4000_ProgDownload
HU_PTA-4000Download
Add-on for PTA-4000+16
HU_PTA-4000_16
Download

If you download something from this website, please, feel free to let a comment or message.

TE-1507 : The memory module for developers !

Hello !

The TE-1507 memory module is now in my PC-1500 !
This module offers a very wide memory space for developers.

It was initially planned to have RAM and EEProm but due to a bad EEProm lot… it’s now full RAM.

Standard memory for Basic/ML :
– from &0000 to &3FFF
– 2 x 16KB switchable by PV or PU (jumper to select active signal)
– read only by removing a jumper
– disabled by removing a jumper

EEProm memory (here it’s RAM) for ML only as system/peripheral ROM extension:
– from &8000 to &BFFF
– 2 x 16KB switchable by PU (as in the CE-158 interface)
– set by jumper if it’s in the PV=0 (like CE-150) or PV=1 (like CE-158 or CE-162E) memory space
– read only by removing a jumper
– disabled by removing a jumper

The two memory addresses can be inverted by placing the enable jumpers on the switch positions (90° move)

Here are the pictures :
TE-1507_H_014TE-1507_H_013

TE-1507_H_015TE-1507_H_017

TE-1507_H_023TE-1507_H_022

TE-1507_H_021TE-1507_H_020

TE-1507_H_019

This module will be a very good investment to expand your PC-1500(A) !
The Team1560 member CGH is working on a ROM builder to add Basic keywords from a wide library. Cool, isn’t it ?

The price for this special module is $75 without shipping costs.

New in the family : PC-1500 RP !

Do you remember the PC-1500 RP2 found in Brazil ?
This new one is the RP and it’s the same for the printer.

PC-1500_RP_015

This is a full set with all accessories and manuals. The instruction manual is only a bad copy.
PC-1500_RP_016PC-1500_RP_002
The case is very clean ! And all accessories are present : power adapter, pens, paper, cables…
PC-1500_RP_003PC-1500_RP_006
And the papers too : connector cover for the printer, sticker for name.
PC-1500_RP_009PC-1500_RP_007
And the big surprise is the PC-1500RP 8K memory module. Uh, all seems to be named PC-1500RP…
PC-1500_RP_008
The case is like the one the the PC-1500RP2 but with two rivets on each side. This makes it stronger.
PC-1500_RP_001PC-1500_RP_005
PC-1500_RP_004PC-1500_RP_014
Differences between the RP and RP2 ? None !
PC-1500_RP_010
Each time the serials are same for the pocket computer and the printer.
PC-1500_RP_013
PC-1500_RP_011
PC-1500_RP_012

Manuals BRLink
PC-1500_RP_INSTR(Not original cover)
Download
PC-1500_RP_PROGDownload

In conclusion i think the RP version is the PC-1500 without memory module (or with 8K) and the RP2 is provided with the 16KB module (Remember the PTA-4000 and PTA-4000+16).
Not much differences but we can consider the two versions.
Now we have 11 PC-1500 versions !

Alles für Sharp Computer : january to june 1987

Alles_fur_Sharp_Computer_87-01
Download
Alles_fur_Sharp_Computer_87-02
Download
Alles_fur_Sharp_Computer_87-03
Download
Alles_fur_Sharp_Computer_87-04
Download
Alles_fur_Sharp_Computer_87-05
Download
Alles_fur_Sharp_Computer_87-06
Download

All the book, manuals, magazines provided here are digitized from my personal collection and for information about the PC-1500’s story. They illustrate all the incredible enjoyment around this pocket computer and all the work of thousands of fans. Feel free to find your own original items.
If you are the copyright owner of some digitized documents and want them to be removed from my website please contact me.
And if you own some other items that could be interesting to be published here please contact me.
And if you are fans and have some story to tell us contact me too !

New hardware coming soon : TE-1504B, a backplane for the PC-1500

I wasn’t very present here these weeks… but was designing new hardware for our pocket computer !

TE-1504 : A simple connector converter HD60 –> simple card connector (horizontal)
TE-1504S : Same as previous but with bus drivers (horizontal)

The all time the missing extension :
TE-1504B : A backplane for the PC-1500 with bus drivers and 5 card connectors (vertical)
Each connector respect the same pin role as on the PC-1500.

TE-1504B_Docu
TE-1504B_Pict01
TE-1504B_Pict02

And there will be two prototype boards :
TE-1504PS : Short version 80×100
TE-1504L : Long version 150×80

Do you have some board ideas for the system ?
